CUNI1 kobber-nikkel lav-resistens legeret tråd Wholesale
Hjem / Produkter / Kobber-nikkel / CUNI1 kobber-nikkel lav-resistens legeret tråd
  • CUNI1 kobber-nikkel lav-resistens legeret tråd
  • CUNI1 kobber-nikkel lav-resistens legeret tråd
  • CUNI1 kobber-nikkel lav-resistens legeret tråd
  • CUNI1 kobber-nikkel lav-resistens legeret tråd
  • CUNI1 kobber-nikkel lav-resistens legeret tråd

CUNI1 kobber-nikkel lav-resistens legeret tråd

CUNI1 kobber-nikkel lav-modstand legeret tråd er det foretrukne materiale til fremstilling af milliohm-niveau modstande. Det er almindeligt anvendt til strømmåling i bilelektronik og batteristyringssystemer (BMS), der producerer ekstremt lavt spændingsfald og varmetab selv under høje strømforhold. I applikationer, hvor der kun kræves en lille temperaturstigning (såsom gulvvarmesystemer, afrimningsanordninger og medicinske varmetæpper), kan CuNi1-tråd bruges som et varmeelement for at give langdistance og ensartet varmefordeling uden at generere lokale hotspots som højmodstandstråde.

PREV：Ingen tidligere artikelNÆSTE：CUNI2 kobber-nikkel svejsbar modstandslegering
  • Specifikation
  • Kontakt os
Karakter CuNi1 CuNi2 CuNi6 CuNi8 CuMn3 CuNi10 CuNi14 CuNi19 CuNi23 CuNi30 CuNi34 CuNi44
NC003 NC005 NC010 NC012 MC012 NC015 NC020 NC025 NC030 NC035 NC040 NC050
Sammensætning (%) Cu Bal Bal Bal Bal Bal Bal Bal Bal Bal Bal Bal Bal
Mn — — — — 3 — 0.3 0 0.5 1 1 1
Ni 1 2 6 8 10 14.2 19 23 30 34 44
Max driftstemperatur (℃) 200 200 220 250 200 250 300 300 300 350 350 400
Resistivitet (μΩ·m @20℃) 0,03±10 % 0,06±10 % 0,1±10 % 0,12±10 % 0,12±10 % 0,15±10 % 0,2±5 % 0,25±5 % 0,35±5 % 0,35±5 % 0,4±5 % 0,49±5 %
Temperaturmodstandskoefficient (×10⁻⁶/℃) <100 <120 <60 ≈57 <38 <50 <38 <25 <16 <10 0 < -8
Termoelektrisk spænding vs kobber (μV/K @20℃) -8 -12 -18 -22 1 -25 -28 -32 -34 -37 -39 -43
Gennemsnitlig termisk udvidelseskoefficient (×10⁻⁶/℃) 17.5 17.5 17.5 17.5 18 17.5 17.5 17.5 17.5 17 16 15
Termisk ledningsevne (W/mK) 145 130 92 75 84 59 48 38 33 27 25 23
Specifik varmekapacitet ved 20 ℃ (J/gK) 0.38 0.38 0.38 0.38 0.39 0.38 0.38 0.38 0.38 0.39 0.4 0.41
Massefylde (g/cm³) 8.9 8.9 8.9 8.9 8.8 8.9 8.9 8.9 8.9 8.9 8.9 8.9
Smeltetemperatur (℃) 1085 1090 1095 1097 1050 1100 1115 1135 1150 1170 1180 1280
Min. trækstyrke (N/mm²) 210 220 250 270 290 290 310 340 350 400 400 420
Forlængelse (%) 25 25 25 25 25 25 25 25 25 25 25 25
